The below guild will teach you exactly how to build an octagon poker table. This particular poker table sits 8 players and is a relatively simple build. The completed octagon poker table measures 4' x 4' with eight distinct seating positions.
To downoad your octagon poker table plans please go to our Free Poker Table Plans page where you will be able to sign up to have all of our available plans, including those showing you how to make an octagon poker table, emailed to you.
The cost to build this table is very low in relation to the 8 foot poker tables as you can get away with one sheet of plywood and half sheets of foam. Please begin on step one. Good luck and remember if you run into trouble or don't understand everything, you can always ask for help in our Poker Table Forum.
All poker table building supplies used to build this poker table are for sale in the online shop including Complete Poker Table Kits.
For the anamation on this build please visit How to Build an Octagon Poker Table Video.
Measuring and Cutting Your Octagon Poker Table
Making The Perfect Octagon Poker Table
Since we're starting with an 8 foot sheet of plywood, the first thing we have to do is cut our wood in half. All you have to do is measure 48 inches from on side and draw a straight line from top to bottom (Figure 1-1). This will seperate our plywood into what we will call sheet A and sheet B.
After you have your line drawn, its a good idea to take a few measurements to make sure that it is true. Once you are happy with the mark, run your circular saw accross it and seperate sheets A and B creating two perfect 4' squares (Figure 1-2).
This is where things could get complex. Fortunately we have already done the math for you. To make the perfect octagon poker table you will measure in from each corner 14 1/16' and make a mark (Figure 1-3). This is a strange measurement, but this is also an odd shaped poker table so we'll let it slide. Once you have all 8 marks done, you can simply connect the dots on each corner (Figure 1-4). If you want to double check your work before cutting, each side of the octagon should be 19 7/8' long. Remember that being off by an eight of an inch or so is not the end of the world as the entire table will be upholstered very soon. Note that these measurements and cuts need to happen to both A and B.
Once you are happy with all of your measurements, you can cut along the lines with your circular saw. At this point your octagon poker table will begin to take shape. Now with your tape measure, measure and mark 2' from the edge on all 8 sides of sheet A and connect the marks to make a 2' ring around the entire octagon (Figure 1-5). This process should be repeated with sheet B but measuring 4.5' from the edge (Figure 1-6). These pieces will eventually become the top and bottom of your octagon rail.
If you are happy with your marks, its time to cut them out. Keep in mind that you will be using the outer ring and the inner octagon from both pieces of wood so be careful. The easiest way to cut these rings is to drop your circular saw into the straight edges and cut that area first. Then you can clean up the corners with a jig saw and everything should come appart clean. When you're done, we will end up with 4 different pieces of wood that we will refer to as A, B, C, and D (Figure 1-7).
Octagon Card Table Plans
Now you can relax and put down your power tools. All of the cutting is done. With the wood work behind up, its time move ahead to Step Three - Building the Octagon Playing Surface.
